Draw.io skill
Agents365-ai/drawio-skill
Draw.io skill is a free, MIT-licensed agent skill by Agents365-ai that produces editable .drawio files instead of flat pictures. It builds architecture, UML, ERD, sequence, C4 and BPMN diagrams from a description or from code, Terraform, Kubernetes, SQL and OpenAPI files, and exports PNG, SVG, PDF or JPG through the draw.io desktop CLI.
Facts checked on against the sources listed at the end of this page.
- GitHub stars
- 10,028
- Skills in the pack
- 1
- Agents supported
- 7plus any agent the skills CLI supports
- License
- MIT
- Last commit
- 1 week ago2 October 2026
- Instruction size
- 1.2k wordsacross its SKILL.md file
How to install Draw.io skill
| Agent | Command | Copy |
|---|---|---|
| Prerequisite | Installs the draw.io desktop CLI on macOS. Version 30 or later is recommended. On Windows and Linux, use the installer from the drawio-desktop releases page. Check with drawio --version. | |
| Claude Code | | |
| Claude Code (manual) | | |
| Cursor, GitHub Copilot and other agents | | |
| Autohand Code | For a project-level install, clone into .autohand/skills/drawio-skill instead. |
Commands as given in the README on 9 October 2026.
What Draw.io skill runs on your machine
- Hooks
- None named in the README.
- Bundled scripts
- Yes. A set of Python scripts in scripts/ run with python3, with diagramctl.py as the main entry point. PNG, SVG, PDF and JPG export needs the draw.io desktop CLI. Graphviz, python-pptx, terraform, docker and kubectl are optional for layout, PowerPoint export and live infrastructure reads.
- Network calls
- Yes. aiicons.py loads brand logos from the unpkg CDN at render time unless you pass --embed. A browser fallback uses diagrams.net URLs.
- API keys needed
- None.
- Tool permissions
- SKILL.md allows Bash, Read, Write and WebFetch.
These are facts read from the repo, not a security rating. Read the files before you install any skill.
What is inside Draw.io skill
| Skill or command | What it makes the agent do |
|---|---|
| drawio-skill | Creates and edits .drawio diagrams from a description or from code, infrastructure files, SQL and API schemas, then reviews, syncs and exports them. |
One skill with a large set of Python scripts. The README lists presets for ERD, UML, sequence, C4, architecture, ML, flowcharts, SysML, BPMN, network topology and swimlanes, Mermaid to .drawio conversion, and a shape search with more than 10,000 official cloud and vendor icons.
A good fit for
- Teams that need diagrams in draw.io format that people can keep editing by hand
- Engineers who want architecture or ER diagrams generated from Terraform, Kubernetes, docker-compose or SQL files
- Documentation that uses cloud provider icons and C4 or sequence diagrams
- Projects that want to re-theme or diff diagrams as the code changes
Skip it if
- Quick diagrams where Mermaid or PlantUML in a Markdown file is enough
- Machines where you cannot install the draw.io desktop CLI, which export needs
- Offline use without the --embed option, since logos load from a CDN by default
How Draw.io skill works
The skill treats a diagram as a source file. It writes an intermediate representation, generates the .drawio XML, and can sync, query, test and review the diagram later, so changes to your code or infrastructure files can update an existing diagram instead of redrawing it.
It checks its own PNG output and applies fixes, and the SKILL.md sets disable-model-invocation, so the agent runs it when you ask for a draw.io diagram. The SKILL.md says to prefer Mermaid or PlantUML when diagrams as code is enough.
- Made by
- Agents365-ai
- Topic
- Design and frontend
- Works with
- Claude Code, Cursor, GitHub Copilot, Codex, OpenClaw, Autohand Code, Hermes
- Website
- agents365-ai.github.io
How much context Draw.io skill uses
| The skill | 1,171 words in its SKILL.md file |
|---|---|
| Loaded at start | Only each skill's name and description. The full text loads when a task needs that skill. |
Word counts are measured from the repo every day. Reference files a skill loads on demand are not counted.
Is Draw.io skill still maintained?
| Last commit | , 1 week ago |
|---|---|
| Latest release | v3.4.0, 14 September 2026 |
| Stars gained in 7 days | Shown after 7 days of tracking |
| Stars gained in 30 days | Shown after 30 days of tracking |
| Open issues and pull requests | 0 |
| Forks | 706 |
Tools Draw.io skill works with
Similar skill packs
Diagram Design
Makes on-brand diagrams and charts as HTML, SVG or PNG, in 42 visual types, matched to your site.
Archify
Turns a description or a repo into a checked, interactive HTML diagram of your system or workflow.
Baoyu's skills
21 skills for content work: cover images, infographics, slide decks, translation, markdown tools and publishing helpers.
Questions about Draw.io skill
Is Draw.io skill free?
Yes. The repository is under the MIT license. It needs the free draw.io desktop CLI for image and PDF export.
What does Draw.io skill output?
Editable .drawio files, which it can export to PNG, SVG, PDF or JPG through the draw.io desktop CLI.
Does it work offline?
Mostly. The core generation needs Python 3. Brand logos load from the unpkg CDN by default, and the --embed option inlines them for offline use.
How do I install it in Claude Code?
Run /plugin marketplace add Agents365-ai/365-skills, then /plugin install drawio. Install the draw.io desktop CLI first if you want exports.
